Texim® e-PTFE

Product detailed description

Uses:

• the material has almost unlimited chemical resistance
• the seal has a high level of compensating ability in terms of micro and especially macro irregularities of the sealing surface
• media leaks that may occur due to flange roughness or irregularities in the flanges used can be sealed perfectly due to the high compressibility and adaptability of the seal
• with ePTFE plates you can cover a wide range of flange shapes and process equipment in harsh aggressive environments
• suitable for the food and pharmaceutical industry

Composition:

• Plate made of 100% pure multidirectionally oriented expanded PTFE

Products:

• 1500x1500 mm plates
• Thickness 0,5mm I 1mm I 1,5mm I 2mm I 3mm I 6mm
• Seals according to drawing or pattern

Certified:

• TA-Luft (VDI 2440) up to 230°C and VDI 2290 40 bar He
• BAM, FDA 21 CFR 177.1550 (PTFE), EG 10/2011
